Outdoor, Super Flexible .500 Inch Corrugated

Low PIM coaxial cable assemblies using super flexible .500 inch corrugated cable

More Info

Featured on Page 10 of our DAS and Wireless Infrastructure Catalog

7-16 DIN Male to 7-16 DIN Male

  • P2RFC-2007-36

  • 7-16 DIN Male Superflex
  • Low PIM 1/2" Super Flexible Cable
  • 7-16 DIN Male to 7-16 DIN Male
  • Length: 3 Feet
  • Helical copper tube construction
  • Available in custom lengths
  • Low PIM: ≤ -155dBc
  • Operating Frequency: up to 3000 MHz
  • VSWR: ≤ 1.10:1 up to 2,400 MHz
  •            ≤ 1.15:1 up to 3,000 MHz

  • P2RFC-2007-72

  • 7-16 DIN Male Superflex
  • Low PIM 1/2" Super Flexible Cable
  • 7-16 DIN Male to 7-16 DIN Male
  • Length: 6 Feet
  • Helical copper tube construction
  • Available in custom lengths
  • Low PIM: ≤ -155dBc
  • Operating Frequency: up to 3000 MHz
  • VSWR: ≤ 1.10:1 up to 2,400 MHz
  •            ≤ 1.15:1 up to 3,000 MHz

  • P2RFC-2007-108

  • 7-16 DIN Male Superflex
  • Low PIM 1/2" Super Flexible Cable
  • 7-16 DIN Male to 7-16 DIN Male
  • Length: 9 Feet
  • Helical copper tube construction
  • Available in custom lengths
  • Low PIM: ≤ -155dBc
  • Operating Frequency: up to 3000 MHz
  • VSWR: ≤ 1.10:1 up to 2,400 MHz
  •            ≤ 1.15:1 up to 3,000 MHz

N Male to N Male

  • P2RFC-2008-36

  • N Male Superlex
  • Low PIM 1/2" Super Flexible Cable
  • N Male to N Male
  • Length: 3 Feet
  • Helical copper tube construction
  • Available in custom lengths
  • Low PIM: ≤ -155dBc
  • Operating Frequency: up to 3000 MHz
  • VSWR: ≤ 1.10:1 up to 2,400 MHz
  •            ≤ 1.15:1 up to 3,000 MHz

  • P2RFC-2008-72

  • N Male Superlex
  • Low PIM 1/2" Super Flexible Cable
  • N Male to N Male
  • Length: 6 Feet
  • Helical copper tube construction
  • Available in custom lengths
  • Low PIM: ≤ -155dBc
  • Operating Frequency: up to 3000 MHz
  • VSWR: ≤ 1.10:1 up to 2,400 MHz
  •            ≤ 1.15:1 up to 3,000 MHz

  • P2RFC-2008-108

  • N Male Superlex
  • Low PIM 1/2" Super Flexible Cable
  • N Male to N Male
  • Length: 9 Feet
  • Helical copper tube construction
  • Available in custom lengths
  • Low PIM: ≤ -155dBc
  • Operating Frequency: up to 3000 MHz
  • VSWR: ≤ 1.10:1 up to 2,400 MHz
  •            ≤ 1.15:1 up to 3,000 MHz
In our constant effort to provide competitively priced, quality products, we reserve the right to change specifications without prior notice. Please contact sales to verify that published specifications are current.
